SDR30RS Reader/Writer


Included in the June 2001, issue of Windows 2000 Magazine

SDLOGIC Technologies is now opening the door to worldwide consumer and commercial smart card application hardware support with the new SDR-30 series of smart card reader/writers. The easy to install single RS-232 cable connection with a PS/2 power tap makes operation of the new SDR-30RS for both desktop and laptop computers a breeze.

Just plug the SDR-30RS in and go! Built on the advanced SDLOGIC INTERSIL (SD-I)
RS-232 chip set, the SDR-30RS is among the most advanced smart card reader/writers to date requiring NO DEVICE DRIVERS in NON-PC/SC mode while maintaining its sub compact size which is only slightly larger than a smart card itself! If you are new to the world of smart cards or a serious user of the technology, you can not and will not go wrong with this small yet attractive and powerful interface tool.

The SDR30RS - the NEXT generation in direct RS-232 smart card interface hardware is here.

Product Features:

  •  Supports microprocessor (MCU) based cards with ISO-7816 T=0 or T=1 protocol
  •  Compliant with ISO-7816/1/2/3
  •  Microsoft PC/SC compatible (SDLOGIC PC/SC driver required)
  •  Direct RS-232 interface with simple command structure
  •  Automatic MCU clock frequency selection for maximum operating efficiency (1.2MHz - 4.0MHz)
  •  Automatic detection of card insertion and removal
  •  Automatic power ON/OFF
  •  Green data LED
  •  Smart card interface short circuit protected
  •  Built to withstand aggressive use and abuse

  •  Compatible with direct RS-232 interface software such as Winexplorer right out of the box with no device drivers needed
  •  Install the simple SDLOGIC PC/SC driver and effortlessly integrate the SDR-30RS into any Windows based PC/SC application

  •  Programming speed from 9,600 baud to 115,200 baud
  •  5VDC @ 50mA supplied via the PS/2 tap
  •  Unit size only 2.5"L x 3.5"W x 0.5"H

Attractive discounts on volume orders. Please email sales@dataphd.net for more information.

Product Notes:
Specifications are subject to change without notice or obligation.
Tested to comply with FCC/CE standards for home or office use.

Certified for development and use with the following operating systems:
